Configure physical members set interfaces ge-0/0/0 description “Connection to Server-Switch fa1/0” set interfaces ge-0/0/0 gigether-options 802.3ad ae10 set interfaces ge-0/0/1 description “Connection to Server-Switch fa2/0” set interfaces ge-0/0/1 gigether-options 802.3ad ae10 4.
Configure port-channel set interfaces ae10 description “Port-channel to Server-Switch” set interfaces ae10 aggregated-ether-options link-speed 1g set interfaces ae10 aggregated-ether-options lacp active set interfaces ae10 unit 0 family ethernet-switching interface-mode access set interfaces ae10 unit 0 family ethernet-switching vlan members VLAN-8 3. Configure the Vlan (interface vlan will be the server’s gateway) Juniper-Router# configure set vlans VLAN-8 description Server-Farm set vlans VLAN-8 vlan-id 8 set vlans VLAN-8 l3-interface irb.8 set interfaces irb unit 8 description “Server Farm Vlan” set interfaces irb unit 8 family inet address 192.168.8.1/24 2. Server-switch have Layer 2 (access mode) connectivity to Juniper-Router. Servers will use Juniper-Router as their gateway and uplink to Internet.
